PDS750S-4B1

Specification

COMPRESSOR

Type: Rotary Twin Screw, Single-Stage, Oil-cooled

Free air delivery (m3/min): 21.2

Rated operating pressure
(MPa)[kgf/cm2][psi]: 0.7[7.14][102]

Compressor oil capacity (L): 80

Air outlet valve: ¾"×2, 2"×1, 3/8"×1

ENGINE

Make/Model: HINO J08C-UT

Type: Direct-Injection, Turbo-Charged

Rated output (kW/min-1)[PS/rpm]: 145/2100[197/2100]

Engine oil capacity (L): 23

Fuel tank capacity (L): 310

Battery: 130F51×2

DIMENSION & WEIGHT

L×W×H (mm): 3650×1685×2095

Dry (Operating) weight (kg): 3030(3370)

Tire Size: 175/80R13 97/95N×4W

Sound power level in decibels (dB): 104

Sound pressure level (dB[A]): 74

Designated emissions regulation: JPN Stage 2

• The total length is the value with the drawbar upright.
• Specifications are subjected to change without any notices.
